In words
Intro
New for season 23-24, it's very similar to the Tour model in the toe piece and brake, while the heel tower has swapped out the three interchangeable springs to adjust the release values (which don't use the usual numbered scale, but letters) for a more traditional screw adjustment. It has a release range of 6-12, 4-9, or 3-5 for lighter skiers and kids. A development that widens the range of Atomic AT bindings (and Salomon/Armada too), with an easier way to adjust the release settings.
Fit
What we said about the Tour applies here; up front nothing changes. The metal guide is there to help with pin alignment, and the large technopolymer lever is easy to operate with gloves on, if a little stiff. It has two classic toe wings with double spring. The tower doesn't change much, apart from the large screw for adjusting the release settings and climbing aid flaps that can sit on the pins without needing to rotate the tower (by 90°) if you're not interested in flat mode. On the downhill the rear pins are among the best at resisting lateral shocks and torsion.
Technical specifications
Materials
aluminum, steel, technopolymer
Type
full pin
Ski brake
yes (80, 90, 100, 110, 120)
Number of mounting screws
9
Crampon slot
Yes
Adjustable release range
Yes
Available versions
Backland Summit 9 BR, Backland Summit 5 BR, Backland Summit 12 LSH, Backland Summit 9 LSH
Walking modes
0, 8°, 13°
Individual weight
400 gr
Drop
9.1 mm
Toe cap weight
119 gr
Heel cap weight
268 gr
Front pin height
33.9 mm
Rear pin height
43 mm
Minimum release range
6 DIN
Maximum release range
12 DIN
Released in
2023
Price
440 €
